E15 15K Heavy-Duty 2-Post 2-Stage Front & Rear Arms
SKU E15-BLUE
Lead time:
by Challenger
Save 36%
Original price
$19,539.60
Original price
$19,539.60
-
Original price
$19,539.60
Original price
$19,539.60
Current price
$12,505.35
$12,505.35
-
$12,505.35
Current price
$12,505.35
-
DESCRIPTION
Challenger designed a new E15 2-post lift to be an economic option for servicing vehicles up to 15,000 lbs. Heavy-duty 2-stage front and 2-stage rear arms offer symmetric lifting capability. Includes a built-in 2 foot column height extension to accommodate higher profile vehicles. The E15 also comes standards with stack adapters.
This lower-cost option doesn’t sacrifice the features you’ve come to expect. The jacketed single-point mechanical lock release system was once exclusive to our CL Series.
Both models are ALI® Certified.
-
FEATURES + BENEFITS
- 15,000 lb. lift capacity
- Heavy-duty 2-stage arms enable heavy-duty symmetric lifting
- Adjustable column height accommodates higher profile vehicles and provides maximum headroom to work underneath vehicles
- Jacketed pulley-less single-point mechanical lock release system that was once exclusive to our CL Series
- Padded overhead shut off system prevents vehicle damage
- Powder coat finish provides long-lasting durability
- Plated arm restraints and arm pins inhibit rust and provide long-lasting durability
- Heavy-duty polyurethane screw pads accommodate a wide range of recommended lifting points
- Standard dual integrated rubber door guards help protect vehicle panels from inadvertent damage
-
SPECIFICATIONS
Model Number E15 Description
Lifting Capacity 15,000 lbs. Lifting Configuration Symmetric Rise Height 6' 5.75"
Overall Height 12' 13"
Drive-Thru Clearance 9' 1.375"
Floor to Overhead Switch 13' 10" / 15' 10"
Minimum Arm Reach 36.5”
Maximum Arm Reach
55”
Screw Pad Height
5.25”-6.75”
Ceiling Height Required
14' 7" / 16' 7"
Motor / Voltage
2HP, 208v - 230v
Speed of Rse
75 s ALI/ETL Certified
Yes Colors Available Red, Blue
-
