Balcrank UP05 1/2" Aluminum AODD Diaphragm Pump #1120-046
Regular price
$780.00
Regular price
-35%
$1,200.00
Sale price
$780.00
Specifications
| Balcrank Part Number | 1120-046 |
| Model | UP05A-NAC-AHC |
| Product Type | Air-Operated Double-Diaphragm Pump |
| Pump Size | 1/2" |
| Construction | Aluminum |
| Air Inlet | 1/4" NPT(F) |
| Fluid Inlet | 1/2" NPT(F) |
| Fluid Outlet | 1/2" NPT(F) |
| Maximum Free Flow | 13.5 GPM (51 L/min) |
| Air Pressure Range | 20–100 PSI (1.5–7 bar) |
| Maximum Solids in Suspension | 3/32" (2.5 mm) |
| Service Bulletin | SB 1211 |
Balcrank UP05 1/2" Aluminum AODD Diaphragm Pump #1120-046
Balcrank #1120-046 is the UP05A-NAC-AHC 1/2" aluminum air-operated double-diaphragm pump. Balcrank rates this UP05 configuration for maximum free flow up to 13.5 GPM.
Recommended Fluids
- Anti-freeze / glycol
- Lubricants
- Used fluids
- Hydraulic oil
Applications
Balcrank identifies the UP05 aluminum pump for medium-volume transfer, dewatering, and fluid evacuation applications.
