Mahle ShopPRO CLS-15 Air Lift & Support Stand #485-80018-00
Shipping information
Enter your delivery ZIP code to see priced freight options for this item. Rates match checkout exactly.
Mahle shipping quote
Shipping is quoted by destination before payment. Select your options, then request your freight quote.
We will confirm the shipping total before sending a payment link.
| Model / Part Number | 485-80018-00 |
| Product Type | Air Lift and Support Stand |
| Capacity | 30,000 lbs (15 tons) |
Mahle CLS-15 — Air Lift and Support Stand
Heavier trucks, buses, and commercial vehicles push past a 10-ton lift's rating, and undersized equipment either can't safely handle the load or forces a shop to turn away the heaviest work it's capable of servicing.
The CLS-15 steps up to a 30,000 lb (15 ton) capacity in the same integrated lift-and-support design as the CLS-10, powered entirely by compressed air. A larger 14" cylinder bore delivers the extra lifting force, while the same air rocker valve control, removable handle with wheels, and pair-operation capability carry over — built for spring, brake, and tire service on the heaviest trucks and buses a shop handles.
Who the CLS-15 Is Built For
- ✅ Shops doing spring, brake, and tire service on the heaviest trucks, buses, and commercial vehicles
- ✅ Techs who want integrated lift-and-support in one tool instead of a jack plus separate stand
- ✅ Operations that have outgrown the CLS-10's 10-ton capacity
- ✅ Bays that want pair operation via the optional air tee connector for synchronized lifting on wide vehicles
What the CLS-15 Is NOT Built For
- ❌ Lighter-duty vehicles where the 10-ton CLS-10 is a better capacity/cost match
- ❌ Shops without a reliable 200 psi shop air supply
What Makes the CLS-15 Different
30,000 lb Capacity
A larger 14" cylinder bore delivers the extra lifting force needed for the heaviest trucks and buses a shop services.
Integrated Lift and Support Design
The CLS-15 combines lifting and holding into a single unit, so techs skip positioning a separate support stand.
Air Rocker Valve Control
Ensures precise, smooth raising and lowering instead of an abrupt on/off lift, even at 15-ton capacity.
- Shops doing spring, brake, and tire service on the heaviest trucks, buses, and commercial vehicles
- Techs who want integrated lift-and-support in one tool instead of a jack plus separate stand
- Operations that have outgrown the CLS-10's 10-ton capacity
- Lighter-duty vehicles where the 10-ton CLS-10 is a better capacity/cost match
- Shops without a reliable 200 psi shop air supply
Is the CLS-15 the Right Lift & Support Stand for Your Shop?
| Capacity | 30,000 lbs (15 tons) |
| Design | Integrated lift + support stand |
| Cylinder Bore | 14" |
| Maximum Lift Height | 37.3" (52.3" with extension) |
Choose the CLS-15 for the heaviest trucks, buses, and commercial vehicles where the CLS-10's 10-ton rating isn't enough margin. Have questions about whether the CLS-15 fits your specific job? Call (817) 865-3707.
Full Specifications — CLS-15
| Part Number | 485-80018-00 |
| Product Type | Air lift and support stand |
| Capacity | 30,000 lbs (15 tons) |
| Minimum Start Height | 17.6" |
| Maximum Lift Height | 37.3" (Without Extension) / 52.3" (With Extension) |
| Stroke | 10" |
| Cylinder Bore | 14" |
| Required Air Pressure | 200 psi |
| Overall Length | 25.5" (Without Handle) / 58.5" (With Handle) |
| Wheel Diameter | 5" |
| Saddle Width | 4.8" (Inside) / 5.5" (Overall) |
| Handle Length | 36.5" |
| Shipping Weight | 230 lbs |
| Warranty | 1 year (parts and labor) |
⚠️ Setup Requirements
- Weight: confirm your dock/receiving area and shop floor can handle this unit’s shipping weight before delivery.
- Setup: Installation/setup is available as a quoted service — it’s not included in the purchase price. Call (817) 865-3707 for a quote if you’d like Alamo’s crew to set it up.
Mahle Warranty — CLS-15
The CLS-15 carries a 1 year (parts and labor) warranty from Mahle.
Warranty service is through Alamo Equipment & Service — call (817) 865-3707 instead of waiting on a manufacturer hotline. Coverage is subject to Mahle warranty terms, conditions, and requirements.
Frequently Asked Questions — Mahle CLS-15
Why Buy the CLS-15 from Alamo Equipment & Service?
- Installation available. Buying online gets you the equipment — setup/install is an extra-charge, quoted service. Call (817) 865-3707 for a quote.
- We service it. Call (817) 865-3707 for maintenance, repairs, or support — and if you ever need warranty work, we register your equipment with the manufacturer and handle the claim directly, so you’re not stuck navigating vendor support on your own.
- We size it with you. 30,000 lb (15 ton) capacity with integrated lift-and-support design — call and we'll confirm it's the right size for your heaviest trucks and buses.
- Ships by freight. The available method and price are shown at checkout.
A shop buying from a pure e-commerce retailer gets a box. A shop buying from Alamo gets a partner.
Your LTL freight rate is calculated at checkout. Each order may contain one lift or other freight-shipped item. Please order parts and additional freight items separately.
