Tuxedo 24 Gallon Self Evacuating #24G-SE-Drain
| Model / Part Number | 24G-SE-Drain |
| Type | Upright portable oil drain, self-evacuating |
| Fluid Capacity | 24 gallons |
| Funnel Diameter | 17 in |
| Adjustable Height | 50 in – 73 in |
| Evacuation Method | Pneumatic self-evacuation |
| Evacuation Hose | 7 ft, with nozzle |
- Level shop floor — no anchoring required, this is a rolling portable drain
- Indoor use
- Shop compressed air line for pneumatic self-evacuation (air pressure gauge & regulator built in)
- Confirm bay clearance under the vehicle for the 50 in – 73 in adjustable funnel height
- Allow room to roll the drain on its casters (2 swivel + 2 fixed) to a waste tank for the 7 ft evacuation hose to reach
- Ships by LTL freight or parcel depending on order size
Tuxedo 24G-SE-Drain \u2014 24 Gallon Self-Evacuating Oil Drain
The Tuxedo 24G-SE-Drain is a 24-gallon upright oil drain with pneumatic self-evacuation a genuinely different design from a manual-pump drain. Shop air pressure, controlled through a built-in air pressure gauge and regulator, pushes collected fluid out through a 7 ft evacuation hose without hand-pumping.
A 17 in diameter plastic funnel with a built-in contamination screen catches fluid on the way in, and the funnel height adjusts from 50 in to 73 in for different vehicle clearances. The steel reservoir tank includes a fill sight tube so you can monitor fluid level, and a durable powder-coat finish stands up to shop use better than a bare poly tank in high-traffic bays.
A storage tray keeps the drain plug, filter, and gasket together during the oil change, and it rolls on two swivel casters plus two fixed wheels for stable positioning during pneumatic evacuation.
Who It's Built For
- Higher-volume service bays wanting faster, hands-free pneumatic evacuation
- Shops with existing shop air already run to the bay
- Techs who want a built-in storage tray for the drain plug, filter, and gasket
What It's NOT Built For
- Shops without a compressed air line \u2014 see the manual-pump 18G-Drain instead
- Lower-volume bays that don't need the extra 6-gallon capacity over the 18G-Drain
Questions about fit or capacity? Call Alamo at (817) 865-3707.
What Makes the 24G-SE-Drain Different
Pneumatic Self-Evacuation No Hand Pumping
Shop air pressure pushes fluid out through the 7 ft hose, controlled by a built-in air pressure gauge and regulator faster than manually pumping a drain empty between jobs.
Steel Reservoir with Fill Sight Tube
The steel tank holds up to shop wear better than a poly tank, and the sight tube still lets you check fluid level without opening the reservoir.
24-Gallon Capacity, 6 Gallons More Than the 18G-Drain
More capacity between evacuations for higher-volume service bays.
Built-In Storage Tray
Keeps the drain plug, filter, and gasket together during the job, a feature the 18G-Drain doesn't include.
Best For
- Shops with shop air wanting faster, hands-free evacuation
- Higher-volume bays needing more capacity between empties
Not Ideal For
- Shops without a compressed air line the 18G-Drain's manual pump needs no air connection
24G-SE-Drain vs. 18G-Drain Pneumatic or Manual Evacuation?
These are genuinely different designs, not just a capacity difference.
| Decision Point | 24G-SE-Drain (this product) | 18G-Drain |
|---|---|---|
| Fluid capacity | 24 gallons | 18 gallons |
| Evacuation method | Pneumatic self-evacuation (air gauge/regulator) | Manual hand pump |
| Reservoir material | Steel, with fill sight tube | Translucent polyethylene |
| Evacuation hose | 7 ft | 4 ft |
Choose the 24G-SE-Drain if you have shop air and want faster, hands-free evacuation with more capacity. Choose the 18G-Drain if you don't need pneumatic evacuation. Call (817) 865-3707 if you're not sure which fits your shop.
Full Specifications — 24G-SE-Drain
| Model / Part Number | 24G-SE-Drain |
| Fluid Capacity | 24 gallons |
| Funnel Diameter | 17 in, plastic, with contamination screen |
| Adjustable Height | 50 in – 73 in |
| Reservoir Material | Steel, with fill sight tube |
| Evacuation Method | Pneumatic self-evacuation, air pressure gauge & regulator |
| Evacuation Hose | 7 ft, with nozzle |
| Mobility | 2x swivel casters + 2x fixed wheels |
| Features | Storage tray (plug, filter & gasket), durable powder-coat finish |
⚠️ Installation Requirements
- Floor: Level shop floor \u2014 no anchoring required, this is a rolling portable unit.
- Air supply: Shop compressed air line for the pneumatic self-evacuation system.
- Bay footprint: Confirm clearance under the vehicle for the 50 in 73 in adjustable funnel height.
- Freight: Delivery within the contiguous 48 states is included in the advertised price.
- Installation: No installation required. This arrives ready to use. Call Alamo at (817) 865-3707 with any questions.
Warranty — 24G-SE-Drain
Tuxedo Distributors, LLC publishes a Limited Warranty (5-year structural / 1-year parts) for its Lifts and Wheel Service equipment. Alamo was not able to locate a manufacturer warranty document that names this specific product category, so no warranty term is advertised here rather than assuming coverage that isn't confirmed in writing.
Have a warranty question before you order? Call Alamo at (817) 865-3707 and we'll help you confirm current coverage directly with Tuxedo.
❓ Frequently Asked Questions — 24G-SE-Drain
Does the 24G-SE-Drain price include shipping?
Yes. The advertised price includes standard freight delivery within the 48 contiguous United States. Additional freight charges apply for Alaska and Hawaii.
What's the difference between the 24G-SE-Drain and 18G-Drain?
The 24G-SE-Drain uses pneumatic (air-powered) self-evacuation, holds 24 gallons in a steel reservoir, and has a longer 7 ft evacuation hose. The 18G-Drain uses a manual hand pump for evacuation and holds 18 gallons in a translucent poly reservoir.
Does the 24G-SE-Drain need shop air?
Yes — pneumatic self-evacuation requires a compressed air connection. If you don't have shop air, the 18G-Drain's manual hand pump doesn't need it.
Is there a published warranty for the 24G-SE-Drain?
Tuxedo's published Limited Warranty document covers Lifts and Wheel Service equipment specifically; Alamo did not find a separate warranty document naming oil drains, so no warranty term is claimed here. Call (817) 865-3707 with warranty questions before you order.
