Tuxedo Air Pump with Hose #AP-10K
| Model / Part Number | AP-10K |
| Type | Air/hydraulic pump with hose |
| Maximum Hydraulic Pressure | 10,000 PSI |
| Air Pressure Range | 25 – 125 PSI |
| Reservoir Capacity | 2.5 liter |
| Reservoir Material | Aluminum |
| Ship Weight | 29 lb |
- No dedicated floor space required — portable bench or floor-standing unit
- Indoor use
- Shop compressed air supply (25–125 PSI operating range) — no electrical connection required
- Treadle can be operated by foot or hand — confirm workspace clearance for the treadle motion
- Includes hose for connecting to hydraulic tooling
- Ships by standard parcel/small freight
Tuxedo AP-10K — Air/Hydraulic Pump with Hose
The Tuxedo AP-10K is an air/hydraulic pump built to power hydraulic tooling and lift accessories that need up to 10,000 PSI of hydraulic pressure. Shop compressed air (25–125 PSI) drives the pump, which converts it to high hydraulic pressure through an all-metal internal design housed in a heavy-duty aluminum reservoir.
The foot-or-hand-operated treadle gives the operator control over pump activation, and a built-in safety relief valve protects the hydraulic components from overloading. The 2.5 liter reservoir capacity and included hose make this a self-contained unit ready to connect to compatible hydraulic tooling.
Who It's Built For
- ✅ Shops that need a portable air/hydraulic pump for hydraulic tooling or accessories
- ✅ Facilities with shop compressed air already available (25–125 PSI)
- ✅ Techs who want foot-or-hand treadle control
What It's NOT Built For
- ❌ Applications requiring hydraulic pressure over 10,000 PSI
- ❌ Shops without a shop air supply — this pump requires compressed air input
Questions about compatibility or capacity? Call Alamo at (817) 865-3707.
What Makes the AP-10K Different
10,000 PSI Maximum Hydraulic Pressure
The pump converts shop air (25–125 PSI input) into up to 10,000 PSI of hydraulic output, suitable for a range of hydraulic tooling applications.
Heavy-Duty Aluminum Reservoir
The aluminum reservoir and all-metal internal moving parts are built for durability under repeated pump cycles.
Foot-or-Hand Treadle Operation
The treadle can be worked by foot or by hand, giving flexibility depending on the task and workspace.
Built-In Safety Relief Valve
Protects hydraulic components from overloading during operation.
✅ Best For
- ✅ Shops needing a portable, air-driven hydraulic pump for compatible tooling
- ✅ Facilities with existing shop compressed air
❌ Not Ideal For
- ❌ Shops without compressed air — this pump needs shop air input to operate
Full Specifications — AP-10K
| Model / Part Number | AP-10K |
| Type | Air/hydraulic pump with hose |
| Maximum Hydraulic Pressure | 10,000 PSI |
| Air Pressure Range | 25 – 125 PSI |
| Oil Flow at 100 PSI | 48 cubic inches/min |
| Oil Flow at 10,000 PSI | 7 cubic inches/min |
| Reservoir Capacity | 2.5 liter (150 cubic inches) |
| Reservoir Material | Aluminum |
| Hydraulic Hose Length | 98.5 in |
| Hydraulic Port Outlet | 3/8 in NPT |
| Ship Weight | 29 lb |
⚠️ Installation Requirements
- Air supply: Shop compressed air, 25–125 PSI operating range.
- Placement: Portable bench or floor-standing unit — confirm workspace clearance for the foot/hand treadle.
- Freight: Delivery within the contiguous 48 states is included in the advertised price.
- Installation: No electrical connection required. Call Alamo at (817) 865-3707 with compatibility questions.
Warranty — AP-10K
Tuxedo Distributors, LLC publishes a Limited Warranty (5-year structural / 1-year parts) for its Lifts and Wheel Service equipment. Alamo was not able to locate a manufacturer warranty document or manufacturer catalog listing naming this specific product, so no warranty term is advertised here rather than assuming coverage that isn't confirmed in writing.
Have a warranty question before you order? Call Alamo at (817) 865-3707 and we'll help you confirm current coverage directly with Tuxedo.
❓ Frequently Asked Questions — AP-10K
Does the AP-10K price include shipping?
Yes. The advertised price includes standard freight delivery within the 48 contiguous United States. Additional freight charges apply for Alaska and Hawaii.
What air supply does the AP-10K need?
Shop compressed air in the 25–125 PSI range.
What is the AP-10K's maximum hydraulic pressure?
10,000 PSI.
Does the AP-10K have a manufacturer warranty?
This product is not listed for sale on Tuxedo's own manufacturer website, and Alamo was not able to locate a manufacturer warranty document naming it specifically. No warranty term is advertised for this product. Call Alamo and we'll help you confirm current coverage directly with Tuxedo.
