AMGO® 9,000 lb Flush-Mount Scissor Lift #XL-9F
AMGO shipping quote
Shipping is quoted by destination before payment. Select your options, then request your freight quote.
We will confirm the shipping total before sending a payment link.
| Model | XL-9F |
| Lifting Capacity | 9,000 lbs |
| Lift Type | Flush-Mount Full-Rise Scissor |
| Max Lifting Height | 74-1/32" |
| Lifting Time | 49 s |
| Motor | 2.0 HP |
- 4" minimum thickness, 3,000 psi minimum concrete
- Flush recess required — see manual for pit dimensions
- Concrete only — do not install on asphalt
- 220V, 60Hz, single-phase; power unit rated 2.0 HP
- Supply cord 12 AWG or larger, properly grounded
- Circuit amperage not specified by AMGO — have your electrician size the breaker
- Full-rise flush scissor; max platform height 74-1/32"
- Minimum platform height 13-3/4"
- Confirm overhead clearance for a raised vehicle before install
AMGO® XL-9F 9,000 lb Flush-Mount Scissor Lift
The AMGO® XL-9F is a 9,000 lb flush-mount full-rise scissor lift that recesses into the floor for a clean, drive-over bay when it is lowered. A control cabinet, synchronized cylinders and a self-lock safety system deliver a stable, repeatable lift for general service and light alignment prep.
Full-rise platforms reach 74-1/32", lock at 71-5/8" and drop to 13-3/4", giving techs strong working height in a bay that stays flush and unobstructed between jobs — ideal for shops that want the floor space back.
Who It's Built For
- Shops that want a full-rise scissor that disappears into the floor when lowered
- Cars, vans and light trucks within the 9,000 lb rating
- Bays where a flush, drive-over floor matters between jobs
- General-service and detail shops that reclaim floor space
- Techs who want fast 49-second cycle times
What It's NOT Built For
- Loads above 9,000 lb — step up to a heavier scissor
- Surface-only bays that cannot pour a flush recess — choose the surface XL-7
- Slabs of unverified thickness — verify concrete before buying
- Motorcycles and ATVs — use a powersport lift
- Ceilings that cannot clear a full-rise raised vehicle
Key Differentiator: Full-rise lift that recesses flush into the floor
The XL-9F drops into a floor recess so the bay is flat and drive-over when lowered, giving a shop full-rise scissor capacity without a permanent obstruction taking up floor space.
- Shops that need the floor clear and flush between lifts
- Bays that cannot cut and pour a flush recess (pick the surface XL-7)
XL-9F vs the Surface XL-7 - Which Scissor Fits Your Floor?
| Model | Capacity | Mount | Max Height | Cycle Time |
|---|---|---|---|---|
| XL-9F | 9,000 lb | Flush-Mount | 74-1/32" | 49 s |
| XL-7 | 7,000 lb | Surface | 78-3/4" | 50 s |
Both XL scissor lifts are stocked in Alamo's catalog. Call (844) 480-6059 and we will help you decide before ordering.
Full Specifications – XL-9F
| Brand | AMGO® Hydraulics |
| Model | XL-9F |
| Part / SKU | ALMAMGXL9F |
| Lifting Capacity | 9,000 lbs |
| Lift Type | Flush-Mount Full-Rise Scissor |
| Max Lifting Height | 74-1/32" |
| Lock Height | 71-5/8" |
| Minimum Height | 13-3/4" |
| Overall Length | 65-1/8" – 80-5/16" |
| Overall Width | 74-13/16" |
| Distance Between Runways | 31-1/2" |
| Lifting Time | 49 s |
| Motor | 2.0 HP, 220V, 60Hz, single-phase |
| Control | Control cabinet, synchronized cylinders, self-lock safety |
| Shipping Weight | Not published by AMGO — confirm before freight quote |
Installation Requirements
- Concrete: Minimum 4" of 3,000 psi concrete with a flush recess per the manual
- Power: 220V single-phase; confirm your service at order
- Overhead: Clear a full-rise raised vehicle before install
- Recess: Flush pit must be cut and poured to AMGO dimensions — we coordinate this
AMGO 5-3-2 Limited Warranty – XL-9F
AMGO Hydraulics backs this scissor lift with a 5-3-2 warranty covering defects in materials and workmanship under normal commercial service. Coverage applies across the 48 contiguous states.
| Term | Component Group | What It Covers |
|---|---|---|
| 5 Years | Steel Structure | Scissor structure, platforms, base frame and steel weldments |
| 3 Years | Hydraulic Parts & Cable | Cylinders, oil seals, hoses, fittings and synchronization cable |
| 2 Years | Electrical & Power Unit | Electrical components and power unit (consumable parts such as rubber pads are excluded) |
Alamo Equipment administers your warranty directly — call (844) 480-6059 and we coordinate parts and claims with AMGO on your behalf.
Coverage excludes consumable wear items and is voided by installation on non-compliant concrete, loading past the rated capacity, or repairs using non-OEM parts. Confirm exact coverage at the time of purchase.
