Atlas® Garage PRO8000EXT 8,000 lb. Extra Tall Hobbyist 4-Post Lift #ATEXH-PRO8000EXT-FPD
Couldn't load pickup availability
| Model / Part Number | ATEXH-PRO8000EXT-FPD |
| Capacity | 8,000 lbs |
| Lift Type | 4-Post extra-tall storage & service lift |
| Lifting Configuration | Single-point lock release, lock-ladder design, double lock safety system |
| Overall Height | 98 1/2" (8' 2 1/2") |
| Minimum Ceiling Height | 8' 6" |
| Overall Width | 115" with motor / 104 1/2" without (9' 7" / 8' 8 1/2") |
| Drive-Thru Clearance | 80 1/2" (6' 8 1/2") |
| Rise Height | 84 1/4" (7' 1/4") to top of runway |
| Motor / Electrical | 110V single phase, 30A breaker required |
| Concrete / Floor Requirement | Standard reinforced slab — confirm exact PSI/depth with Alamo before install |
- Standard reinforced slab — confirm exact PSI/depth with Alamo before install
- Verify with Alamo before ordering
- 110V single phase, 30A breaker required
- Have an electrician confirm your circuit before install day
- Plan for 98 1/2" (8' 2 1/2") overall lift height
- Measure to lowest obstruction, not peak
Atlas PRO8000EXT — 8,000 lbs 4-Post extra-tall storage & service lift
A stored vehicle overhead does no good if there isn't room to actually stand up and work underneath it — crouched-over storage defeats the point of a taller garage. The Atlas PRO8000EXT solves that by taking the standard PRO8000 platform and adding 12" of extra clearance under the runways, turning that headroom into real usable space instead of wasted ceiling. Call Alamo at (844) 480-6059 to confirm your ceiling height before ordering.
Who the PRO8000EXT Is Built For
- Garages with taller ceilings that want the extra vertical clearance to actually stand and work under a vehicle stored on the runways, not just squeeze underneath
- Hobbyists storing taller vehicles — trucks, vans, lifted SUVs — that need more headroom than the standard PRO8000 provides
- Buyers who specifically need the extra 12" of clearance under the runways compared to the standard PRO8000 and are willing to trade for a taller minimum ceiling requirement
- Collectors who use the space under a stored vehicle as a real second workstation, not just parking overflow
- Garage owners who have already confirmed an 8' 6" or taller ceiling and want to maximize what that height gives them
What the PRO8000EXT Is NOT Built For
- ❌ Garages with ceilings under 8'6" — the taller columns won't fit
- ❌ Shops needing ALI/ETL certification
Questions about fit or capacity? Call Alamo at (844) 480-6059.
What Makes the PRO8000EXT Different
8,000 lbs of Capacity with 12" More Clearance
Rated for 8,000 lbs with 84 1/4" (7' 1/4") of rise height to the top of the runway — a meaningful 12" more than the standard PRO8000 — the PRO8000EXT is built for garages that want to actually use the space underneath a stored vehicle.
Same Proven Lock System, Taller Platform
A single-point lock release, lock-ladder design, and double lock safety system carry over from the standard PRO8000, engineered the same reliable way but built into a taller frame.
Requires a Taller Ceiling Than the Standard PRO8000
The PRO8000EXT needs an 8' 6" minimum ceiling — taller than the standard PRO8000's 7' 6" requirement. Measure your garage ceiling carefully before ordering; this is the tradeoff for the extra clearance underneath.
Standard Electrical and Slab Requirements
The PRO8000EXT runs on 110V single-phase power with a 30A breaker required, and needs a standard reinforced slab — confirm exact PSI and depth with Alamo. It carries Atlas's 2-year structural / 1-year hydraulic warranty, serviced through Alamo directly. Call (844) 480-6059 for any claim.
Same Footprint, More Height
At 115" wide with the motor (104 1/2" without) and 80 1/2" of drive-thru clearance — matching the standard PRO8000's footprint — the PRO8000EXT delivers extra height without needing extra floor space.
- ✅ Garages with taller ceilings that want extra under-vehicle clearance for standing/working room
- ✅ Hobbyists storing taller vehicles or wanting more headroom beneath the stored vehicle
- ✅ Buyers who need the extra 12" of clearance under runways versus the standard PRO8000
- ❌ Garages with ceilings under 8'6" — the taller columns won't fit
- ❌ Shops needing ALI/ETL certification
PRO8000EXT vs. Atlas Garage PRO8000 (8,000 lb) — Which Lift Is Right for Your Shop?
| Decision Point | PRO8000EXT | Atlas Garage PRO8000 (8,000 lb) |
|---|---|---|
| Capacity | 8,000 lbs | 8,000 lbs |
| Column height | 98 1/2" — extra tall for more under-vehicle clearance | 83" — standard height |
| Best fit | Taller vehicles / extra clearance below the lift | Standard garage ceiling heights |
Choose the PRO8000EXT for extra under-vehicle clearance — 79" versus 67" on the standard PRO8000. Choose the standard PRO8000 for a lower overall column height if your ceiling is tighter. Both stay inside Alamo’s catalog — call (844) 480-6059.
Full Specifications — PRO8000EXT
| Model / Part Number | ATEXH-PRO8000EXT-FPD |
| Capacity | 8,000 lbs |
| Lift Type | 4-Post extra-tall storage & service lift |
| Lifting Configuration | Single-point lock release, lock-ladder design, double lock safety system |
| Overall Height | 98 1/2" (8' 2 1/2") |
| Minimum Ceiling Height | 8' 6" |
| Overall Width | 115" with motor / 104 1/2" without (9' 7" / 8' 8 1/2") |
| Drive-Thru Clearance | 80 1/2" (6' 8 1/2") |
| Rise Height | 84 1/4" (7' 1/4") to top of runway |
| Motor / Electrical | 110V single phase, 30A breaker required |
| Concrete / Floor Requirement | Standard reinforced slab — confirm exact PSI/depth with Alamo before install |
| Warranty | 2-year structural / 1-year hydraulic — parts only |
| Runway Length | 165 3/4" (13' 9 3/4") |
| Clearance Under Runways | 79" (6' 7") |
| Length Between Columns | 157 1/2" (13' 1 1/2") |
| Shipping Weight | 1,850 lbs |
⚠️ Installation Requirements
- Ceiling height: Plan for 98 1/2" (8' 2 1/2") overall lift height; measure to the lowest obstruction.
- Electrical: 110V single phase, 30A breaker required; consult an electrician for exact breaker sizing.
- Floor / Concrete: Standard reinforced slab — confirm exact PSI/depth with Alamo before install.
- Bay width: Confirm 115" with motor / 104 1/2" without (9' 7" / 8' 8 1/2") floor width clearance; measure before ordering.
- Surface anchoring: Anchor per manufacturer specification where applicable — do not skip anchoring on production bays.
- Installation: Alamo installs every lift we sell. Call (844) 480-6059 to schedule.
Atlas Warranty — PRO8000EXT
Atlas backs the PRO8000EXT with its published warranty terms for this model — verified from Atlas’s own product documentation (manufacturer-web source). Coverage varies by model in the Atlas standard car lift line; the terms below are specific to the PRO8000EXT and should not be assumed to apply to other Atlas models.
| Component | Coverage Term |
|---|---|
| Structural components | 2 years |
| Hydraulic components | 1 year |
| Wear items & accessories | Not covered (consumable, parts-only warranty) |
Warranty service is through Alamo Equipment & Service. When you buy from us, you are not waiting on a manufacturer hotline — call (844) 480-6059 and we handle it.
❓ Frequently Asked Questions — PRO8000EXT
Is the Atlas PRO8000EXT ALI certified?
The PRO8000EXT is a commercial-grade hobbyist 4-post lift; the live Atlas source does not list ALI certification.
What ceiling height does the PRO8000EXT need?
Column height is 98 1/2" (8' 2 1/2") — plan for at least 8'6" of clearance to the lowest obstruction.
How is the PRO8000EXT different from the standard PRO8000?
Same 8,000 lb capacity and footprint, but taller columns (98 1/2" vs 83") for 12" more clearance under the runways.
What power does the PRO8000EXT need?
110V single-phase power on a dedicated 30-amp breaker.
Why Buy the PRO8000EXT from Alamo Equipment & Service?
- We install it. Every Atlas PRO8000EXT we sell can be professionally installed by our team — including confirming your ceiling clearance before we anchor anything.
- We service it. Need support after install? Call (844) 480-6059 — you reach the team that installed it, not a manufacturer hotline.
- We size it with you. Not sure if your ceiling clears the PRO8000EXT's 98 1/2" tall profile? Call and we will confirm before you order — this is the one measurement you cannot skip.
- Free shipping. The PRO8000EXT ships free to all 48 contiguous states.
- Expert comparison help. Not sure if you need the extra clearance of the PRO8000EXT over the standard PRO8000? Call (844) 480-6059 — we will help you decide based on your actual ceiling height.
A shop buying from a pure e-commerce retailer gets a box. A shop buying from Alamo gets a partner.
Shipping Information:
Customers may pick up their lift at the nearest freight terminal at no additional cost.
You will need to provide your own trailer. Terminal staff will safely load the lift onto your trailer. The RECEIVER/CUSTOMER is solely responsible for properly securing the load for transport.
To schedule a pickup, contact us at info@alamoequipment.com or
(844) 480-6059. Please include the lift model and your zip code so we can direct you to the appropriate terminal.
Atlas Warranty Information
- 5-Year Structural Warranty
- 2-Year Hydraulic-Power Warranty
