BendPak HD-973P Tri-Level Parking Lift 9,000/7,000 lb #5175238

BendPak HD-973P — Tri-Level Parking Lift with 9,000 lb Lower Deck and 7,000 lb Upper Platform

Running out of parking does not mean you have to run out of building. The BendPak HD-973P is a tri-level parking lift that puts three vehicles in the footprint of one parking space: a car on the floor, one on the 9,000 lb lower deck, and one on the 7,000 lb upper platform — sedans, SUVs, and full-size trucks included.

What sets the HD-973P apart from typical triple-stackers is how it uses height. Its columns stand 157.75 in with no bulky mechanisms projecting above the lift, so it fits garages and shops that conventional tri-level systems rule out — while the lower deck still delivers a full 70 in of rise. And because the two platforms operate independently, you can lower the bottom deck to swap a car without touching the vehicle stored above it.

Who the BendPak HD-973P Is Built For

• Parking-constrained operations — storage facilities, collections, dealerships, and serious home garages that need three vehicles in one parking footprint instead of a bigger building.
• Sites with ceilings that rule out conventional triple-stackers — 157.75 in columns and a compact design that avoids overhead mechanisms fit where taller systems can't.
• Operators who rotate vehicles constantly — the independently operated platforms let you vary deck heights and spacing, and swap a lower-level car without lowering the vehicle above.
• Mixed fleets of sedans, SUVs, and full-size trucks — a 9,000 lb lower deck and 7,000 lb upper platform carry the range most facilities actually store.
• Indoor or outdoor installations — galvanized or powder-coat finish, and a base-frame design that suits stand-alone use or rows of multiple units for maximum density.

What the BendPak HD-973P Is NOT Built For

This is not the lift for bays that can't carry 157.75 in of column plus two stacked vehicles — no tri-level system forgives a low ceiling. It's also not for vehicles over the per-deck ratings (9,000 lb lower, 7,000 lb upper), and it needs real infrastructure: a 6.5 in / 3,000 psi concrete slab, a 22-amp circuit, and 75-125 psi compressed air for the safety-lock release. A site that can't supply those three things isn't ready for any tri-level lift.

Important sizing note: measure ceiling against the 157.75 in columns plus stacked vehicle heights, the 110.5 x 241.75 in footprint, and confirm loaded weights per deck before purchase.

What Makes the BendPak HD-973P Different

Tri-level parking that fits real ceiling heights

Most triple-stacking systems are too tall for practical use in garages and shops. The HD-973P's proprietary design avoids bulky mechanisms that project high above the lift, keeping the columns at 157.75 in while the lower space still yields a full 70 in of rise — vertical storage without a massive commercial structure.

• 157.75 in column height
• 70 in max rise (72.25 in max lifting height)
• Indoor or outdoor installation

Independent platforms you control separately

Typical multi-level stackers tether the bottom platform to the upper one — both move together at a fixed distance. The HD-973P's two platforms operate independently, so you can vary vehicle heights and spacing between decks and lower the bottom platform without disturbing the vehicle stored above it.

• 13 locking positions spaced 4 in apart
• Air-powered lock release
• Variable deck heights and spacing

Safety engineering built for stored vehicles

Multi-position safety locks with automatic engagement, redundant anti-fall spring-loaded safety catches, independent backup slack-cable safety latches, and a padded trip bar with limit switch that prevents the lower vehicle from contacting the upper platform.

• Locks every 4 in on adjustable lock ladders
• Redundant anti-fall devices
• Padded trip bar with limit switch

Heavy-duty construction with a weight-displacing base

Rugged welded-steel construction, full-length aluminum platform decking, powerful hydraulic cylinders, and heavy-duty 3/8 in lifting cables. The wide base-frame design distributes the load across the slab, and non-skid runway surfaces keep tires planted during drive-on.

• Full-length aluminum decking
• 3/8 in lifting cables
• Galvanized or powder-coat finish

Expandable for storage and light service

The HD-973P can be configured for drive-thru operation and combined into rows of multiple units. Optional drive-thru ramps and 4,500 lb air-hydraulic rolling jacks expand how the lift works for storage-plus-service bays.

• Optional 4,500 lb rolling jacks
• Drive-thru configuration available
• Stand-alone or multi-unit rows

Best For

• Tripling parking capacity without construction
• Low-ceiling garages and shops
• Constantly rotating vehicle storage
• Indoor or outdoor installation
• Storage plus light-service bays (with rolling jacks)

Not Ideal For

• Bays under the 157.75 in column height
• Vehicles over 9,000 / 7,000 lb per deck
• Sites without the required air and power
• Full-rise daily service work (70 in max rise)

BendPak HD-973P vs typical tethered tri-level stackers

The HD-973P trades tethered simplicity for control and height savings — independent decks, variable spacing, and a column height that fits shops and garages most triple-stackers can't.

Full Specifications - BendPak HD-973P

Capacities & Rise

Locking & Controls

Dimensions

Platform & Runways

Power & Delivery

BendPak Warranty - BendPak HD-973P

BendPak covers the HD-973P — a commercial parking lift — under its published Commercial Parking Lift limited warranty: structure, hydraulics, and components each covered separately, coordinated through Alamo.

Warranty service is coordinated through Alamo Equipment & Service — call (817) 865-3707 and we help get the issue moving.

Warranty terms can change. Confirm exact coverage at the time of purchase. Warranty can be void if the lift is installed improperly or not anchored per spec.
