Samson PumpMaster 4 - 5:1 For 60 inch Oil Tanks with bung bushing #460
SKU 460
Lead time:
by Samson
Original price
$962.20
-
Original price
$962.20
Original price
$962.20
$962.20
-
$962.20
Current price
$962.20
-
DESCRIPTION
60" tank with bung adaptor 20.5 lb (9,3 kg)
Double-acting air-operated medium-pressure pumps for dispensing lubricants in medium to large-size installations that include multiple outlets with simultaneous operation. Pumps include a height-adjustable bung adaptor 2" NPTM for drum and tank bung mounting. Built-in port for optional (PN 609 007) pressure relief valve.
Typically used in workshops, service stations, fast lube centers, fleet maintenance, mining, agriculture, armed forces, construction, trains, etc.
-
APPLICATIONS
Fluids Handled
- Synthetic and mineral-based oil
- Transmission fluid
- Hydraulic oil
- Gear lube
-
SPECIFICATIONS
Model # Samson 460 Pressure Ratio 3:1 Air pressure operating range 20 to 140 psi (1,5 - 10 bar)
Air consumption (1) 14 scfm (400 NL/min)
Maximum fluid outlet pressure 700 psi (50 bar)
Air motor diameter 3 1/2" (88 mm)
Air motor effective diameter
2 1/2" (60 mm)
Air Motor Stroke 4" (100 mm)
Delivery at 125 cpm 2.7 US gpm (10 l/min)
Maximum free flow delivery (2) 6.6 US gpm (25 l/min)
Air Inlet 3/8" NPTF
Fluid Inlet (stub pump only) 1" NPTF
Fluid Outlet 3/4" NPTF
Wetted and seal materials Aluminum / Steel / Polyurethane / NBR / PTFE Noise (3) 80 dB Simultaneous Dispense Points 1-2 Max. Line Length 200' (60 m) Pump Description Standard Duty Medium Pressure *Image is a representation of this item. Actual item may vary.*
-
DOWNLOADS
Samson 413 PumpMaster 4 - 5:1 Pump 275/500 Oil Tank Unit
