Tuxedo TC-770 Truck Changer #TC-770-T
| Model / Part Number | TC-770-T |
| Type | Heavy-duty hydraulic truck/OTR tire changer |
| Max Wheel Diameter | 64.5 in |
| Max Wheel Width | 31.5 in |
| Inside Rim Clamp Range | 14 in – 26 in |
| Power | 220V – 20 Amp – 1PH |
| Ship Weight | 1,690 lb |
- Level concrete shop floor rated for a 1,690 lb machine
- Confirm floor load capacity for heavy truck/OTR wheel handling
- Indoor use
- Dedicated 220V, 20 Amp, single-phase circuit for the hydraulic pump
- Confirm outlet location relative to intended placement
- Confirm bay space for the movable control stand and rotating four-jaw chuck
- Confirm ceiling/door clearance for large truck/OTR wheels moving in and out
- Ships by LTL freight (heavy freight, confirm dock/liftgate needs)
Tuxedo TC-770-T — Heavy Truck Tire Changer
The Tuxedo TC-770-T is a dedicated heavy-duty hydraulic tire changer for truck, tractor, and earth-mover wheels — an entirely different machine class from the pneumatic swing-arm changers in Alamo's Tuxedo lineup. A four-jaw rotating chuck with two speeds handles wheels up to 64.5 in in diameter and 31.5 in wide, powered by a pressure-regulated hydraulic pump with a quick-change mount/demount arm.
The control unit sits on its own movable stand, giving the operator flexibility to position controls relative to the wheel being worked. This is heavy shop equipment built for commercial truck tire service, not a scaled-up car tire changer.
Who It's Built For
- ✅ Commercial truck, tractor, and earth-mover tire service
- ✅ Shops handling wheels up to 64.5 in diameter that a car/light-truck changer can't touch
- ✅ Facilities with 220V power available for a heavy hydraulic pump
What It's NOT Built For
- ❌ Cars and light trucks — see Alamo's TC-530 or TC-950 instead
- ❌ Shops without 220V, 20 Amp single-phase power available
Questions about fit or capacity? Call Alamo at (817) 865-3707.
What Makes the TC-770-T Different
Four-Jaw Rotating Chuck, Two Speeds
Grips large truck/OTR wheels securely and rotates at two speed settings for the mount/demount process.
Pressure-Regulated Hydraulic Pump
Generates the clamping and mount/demount force needed for heavy truck and earth-mover wheels — a fundamentally different power system from the pneumatic clamps on Alamo's car/light-truck changers.
Movable Control Stand
Positions the operator controls independently of the chuck for better working access around large wheels.
Quick-Change Mount/Demount Arm
Speeds up tool changeovers between mounting and demounting steps on large wheels.
✅ Best For
- ✅ Commercial truck, tractor, and earth-mover shops
- ✅ Wheels up to 64.5 in diameter that need hydraulic, not pneumatic, mount/demount force
❌ Not Ideal For
- ❌ Passenger car or light truck tire service
Full Specifications — TC-770-T
| Model / Part Number | TC-770-T |
| Type | Heavy-duty hydraulic truck/OTR tire changer |
| Max Wheel Diameter | 64.5 in |
| Max Wheel Width | 31.5 in |
| Inside Rim Clamp Range | 14 in – 26 in |
| Power | 220V – 20 Amp – 1PH |
| Ship Weight | 1,690 lb |
| Design | Four-jaw rotating chuck, two speeds; movable control stand; pressure-regulated hydraulic pump; quick-change mount/demount arm |
| Application | Trucks, tractors, and earth movers |
⚠️ Installation Requirements
- Floor: Level concrete shop floor rated for a 1,690 lb machine handling large truck/OTR wheels.
- Power: Dedicated 220V, 20 Amp, single-phase circuit for the hydraulic pump.
- Bay footprint: Confirm room for the movable control stand and rotating chuck, plus clearance for large wheels in and out.
- Freight: Delivery within the contiguous 48 states is included in the advertised price; this is heavy freight — confirm dock/liftgate needs.
- Installation: Call Alamo at (817) 865-3707 to coordinate delivery and setup.
Warranty — TC-770-T
Tuxedo Distributors, LLC publishes a Limited Warranty (5-year structural / 1-year parts) for its Lifts and Wheel Service equipment. The manual covers assembly, the hydraulic circuit, the electrical scheme, and transport/storage only — it does not contain a warranty section. The TC-770-T is a heavy-duty hydraulic truck/OTR tire changer, a mechanically different machine from the pneumatic swing-arm changers elsewhere in Alamo's Tuxedo lineup that carry the standard Lifts/Wheel Service warranty, so that warranty is not assumed to carry over by category alone.
Have a warranty question before you order? Call Alamo at (817) 865-3707 and we'll help you confirm current coverage directly with Tuxedo.
❓ Frequently Asked Questions — TC-770-T
Does the TC-770-T price include shipping?
Yes. The advertised price includes standard freight delivery within the 48 contiguous United States. Additional freight charges apply for Alaska and Hawaii.
What's the maximum wheel size for the TC-770-T?
64.5 in diameter, 31.5 in wide — sized for truck, tractor, and earth-mover wheels.
What power does the TC-770-T need?
A dedicated 220V, 20 Amp, single-phase circuit for the hydraulic pump.
What is the TC-770-T's warranty?
Alamo could not locate a manufacturer warranty document for the TC-770-T. Call (817) 865-3707 and we'll help confirm current coverage directly with Tuxedo before you order.
