In-Ground & Flush Mount Lifts
In-ground and flush-mount vehicle lifts deliver a level shop floor when raised down — the cleanest possible aesthetic for dealership showrooms, detail bays, and shops with strict floor-clearance requirements. Available in scissor and 4-post platform configurations from Challenger, Stratus, and Hofmann with capacities from 7,000 to 14,000 lbs. Requires pre-installation site preparation and concrete cutting. Alamo Equipment coordinates installation with certified contractors and is an authorized dealer for all major in-ground brands.
In-Ground & Flush-Mount Lifts FAQs
In-ground and flush-mount lifts deliver a level shop floor when lowered— the cleanest possible look for dealerships, detail bays, and design-focused service environments.
An in-ground lift has its hydraulic cylinder and lift mechanism installed below the shop floor in an engineered concrete pit. When lowered, the lift surface sits flush with the floor — leaving an unobstructed walking surface and a clean visual appearance.
Both finish flush with the floor when lowered. In-ground lifts have their working mechanism beneath the floor (typically 2-post or single-post designs with the cylinder buried). Flush-mount scissor or 4-post lifts have their working mechanism within a shallow recess cut into the floor.
The primary advantage is aesthetic — dealership showrooms, detail bays, and any shop where the floor needs to look clean and uncluttered when not in use. They also eliminate the trip hazard of a surface-mounted lift base plate.
In-ground installation requires cutting the existing concrete floor, excavating to the manufacturer's depth specification, installing the lift cassette or cylinder housing, plumbing, hydraulic, and electrical service to the lift, pouring new concrete around the lift, and finishing the floor to flush tolerance. Typical installation runs 2 to 5 days, depending on lift type and site conditions.
Yes, but it requires the existing concrete floor to be cut and the site to be excavated. Soil conditions, existing utilities under the floor (electrical, plumbing, drains), and access for excavation equipment all affect feasibility. Most in-ground installs require a site survey before purchase.
Most in-ground 2-post lifts are rated 9,000 to 18,000 lbs — similar to surface-mounted equivalents. Flush-mount scissor and 4-post platforms typically run 6,000 to 14,000 lbs.
Yes — typically 30 to 60% higher total installed cost when you include the concrete cutting, excavation, plumbing, and finish work. For shops that need the aesthetic, the premium is justified. For pure-service shops, surface-mounted equivalents are usually the better value.
Several in-ground lift models in this collection carry current ALI Gold Label certification. Check individual product pages for certification status.
