2 Post Asymmetric

Asymmetric lifts rotate the columns inward and shift the vehicle rearward on the arms so the driver's door opens clear of the post. This is the main reason most passenger-car shops choose asymmetric over symmetric. For heavy-duty trucks where the weight centering outweighs door clearance, symmetric configurations remain the preferred design.

Asymmetric lifts are designed for passenger cars, crossovers, SUVs, and light-duty trucks with gross vehicle weights up to about 14,000 lbs. They are the standard configuration in most independent shops and franchise bays servicing the general passenger and light-truck fleet.

Models range from 9,000 lbs for standard passenger cars to 14,000 lbs for heavier light trucks. Most mixed passenger-and-light-truck bays find a 10,000 to 12,000 lb model sufficient. Always verify gross vehicle weight before selecting lift capacity.

Overhead asymmetric lifts connect the columns with a crossbar at the top — more rigid, but require 11 to 12 feet of ceiling clearance. Floor-plate models connect at the floor level, eliminating the overhead
beam and fitting ceilings as low as 9 to 10 feet. Both deliver the same asymmetric positioning benefit for door clearance.

Most modern asymmetric lifts use swing-arm adapters that accommodate standard OEM pinch welds on domestic and import vehicles. Some aluminum unibody platforms, EV platforms, and specialty vehicles require additional adapter kits. Always verify compatibility with the specific year, make, and model before lifting.

Minimum 4 inches of 3,000 PSI concrete in good condition — identical to symmetric models. Higher-capacity 12,000 to 14,000 lb versions may require 4.25 to 6 inches at higher PSI. Check the specific model's installation manual and have the slab evaluated if the age or thickness is unknown.

Challenger, Atlas, APlusLift, and Stratus all offer ALI Gold Label certified asymmetric configurations within this collection. ALI certifies specific model and capacity combinations, so look for the ALI certification badge on individual listings to confirm current certification status at the time of purchase. Not every asymmetric model from these brands is automatically certified.

No. Asymmetric 2-post lifts raise the vehicle with the wheels hanging free. Wheel alignment requires the wheels to remain loaded on a surface with turn plates and slip plates positioned underneath them. For alignment work, use a drive-on scissor alignment or a 4-post runway lift.
