Tuxedo 6,000 lb Mobile Single Column Lift - Low Profile #MSC-6KLP-BLK
| Model / Part Number | MSC-6KLP-BLK |
| Capacity | 6,000 lb |
| Type | iMOBILE mobile single column lift, low profile, black finish |
| Lift Rise Height | 72 in |
| Drive-Over Height | 3-15/16 in |
| Minimum Ceiling Height | 9 ft |
| Power | 115V, 15A, single-phase |
| Ship Weight | 1,850 lb |
- Level, load-rated shop floor
- Mobile design — no permanent anchoring required
- Indoor use, minimum 9 ft ceiling clearance at full rise
- 115V, 15A, single-phase electrical service
- Have a qualified electrician confirm circuit capacity if running multiple units
- Drive-over ramps at 3-15/16 in height allow drive-over vehicle loading
- Pallet-jack feature allows positioning the lift under the vehicle for loading
- Ships via LTL freight
iDEAL iMOBILE MSC-6KLP-BLK — 6,000 lb Low-Profile Mobile Single Column Lift, Black Finish
The Tuxedo MSC-6KLP-BLK is the black-finish version of the MSC-6KLP iMOBILE mobile single-column lift, rated for 6,000 lb with a low-profile design built for limited space and situations where lift portability matters. The low drive-over ramp height (3-15/16 in) allows drive-over vehicle loading, while a pallet-jack feature also lets the lift be positioned under the vehicle for loading.
Specifications and functionality are identical to the standard-finish MSC-6KLP: 72 in full rise height, 9 ft minimum ceiling clearance, main-side arm reach of 19-11/16 in to 26 in, and off-side arm reach of 24-5/8 in to 34 in. The only difference is the black finish.
Due to its unique low-profile design and portability, the MSC-6KLP-BLK is a practical solution for a homeowner with limited garage space or a shop looking to add mobile lift capacity without a permanent two-post or four-post installation, in a black-finish machine.
Who It's Built For
- ✅ Homeowners and shops with limited space needing a lift that can be moved and positioned as needed
- ✅ Facilities wanting drive-over or pallet-jack-style loading instead of driving onto fixed runways
- ✅ Shops that prefer a black-finish machine to match other black-finish equipment
What It's NOT Built For
- ❌ Vehicles or loads exceeding 6,000 lb
- ❌ Bays with less than 9 ft of ceiling clearance at full rise
Questions about fit, freight, or capacity? Call Alamo at (817) 865-3707.
What Makes the MSC-6KLP-BLK Different
Same Low-Profile Drive-Over Design
A 3-15/16 in drive-over ramp height allows the vehicle to be driven directly onto the lift, while the pallet-jack feature also allows positioning under the vehicle for loading — identical to the standard-finish model.
Black Finish
The only difference from the standard MSC-6KLP is the black finish — all capacities, dimensions, and power requirements are identical.
6,000 lb Capacity, 72 in Rise
Rated for 6,000 lb with a full rise height of 72 in.
Mobility
As an iMOBILE lift, the MSC-6KLP-BLK can be moved and repositioned as needed instead of being permanently anchored to one bay.
Footprint
45-3/16 in wide x 101-9/16 in deep x 102-3/8 in tall; confirm 9 ft minimum ceiling height before ordering.
✅ Best For
- ✅ Homeowners and shops with limited, non-dedicated lift space
- ✅ Facilities wanting drive-over loading without fixed runways
- ✅ Shops standardizing on black-finish equipment
❌ Not Ideal For
- ❌ Vehicles over 6,000 lb
- ❌ Bays with less than 9 ft of ceiling clearance at full rise
MSC-6KLP-BLK vs. MSC-6KLP — Which Finish Is Right for Your Shop?
Same machine, same specs — the only difference is finish.
| Decision Point | MSC-6KLP-BLK | MSC-6KLP |
|---|---|---|
| Finish | Black | Standard iDEAL finish |
| Capacity | 6,000 lb | 6,000 lb |
| Lift rise height | 72 in | 72 in |
| Drive-over height | 3-15/16 in | 3-15/16 in |
Choose whichever finish suits your shop — there is no functional or capacity difference between the two. Call (817) 865-3707 with questions.
Full Specifications — MSC-6KLP-BLK
| Model / Part Number | MSC-6KLP-BLK |
| Capacity | 6,000 lb |
| Width Overall | 45-3/16 in |
| Height Overall | 102-3/8 in |
| Depth / Length Overall | 101-9/16 in |
| Lift Rise Height | 72 in |
| Minimum Ceiling Height | 9 ft |
| Swivel Pad Height (Adj.) | 3-15/16 in – 6-5/16 in |
| Main Side Arm Reach | 19-11/16 in – 26 in |
| Off Side Arm Reach | 24-5/8 in – 34 in |
| Drive-Over Height | 3-15/16 in |
| Finish | Black |
| Power | 115V, 15A, single-phase |
| Ship Weight | 1,850 lb |
| Shipping Dimensions | 99 in L x 44 in W x 42 in H |
⚠️ Installation Requirements
- Floor: Level, load-rated shop floor; mobile design, no permanent anchoring required.
- Electrical: 115V, 15A, single-phase circuit.
- Ceiling height: Confirm at least 9 ft of clearance at full 72 in rise.
- Freight: Standard freight delivery within the 48 contiguous United States is included in the advertised price.
- Installation: Call Alamo at (817) 865-3707 to coordinate delivery and setup guidance.
Warranty — MSC-6KLP-BLK
For exact warranty terms and coverage on the MSC-6KLP-BLK, please contact Alamo Equipment at (817) 865-3707.
❓ Frequently Asked Questions — MSC-6KLP-BLK
Does the MSC-6KLP-BLK price include shipping?
Yes. The advertised price includes standard freight delivery within the 48 contiguous United States. Additional freight charges apply for Alaska and Hawaii.
What's different between this and the standard-finish MSC-6KLP?
Only the finish. This model has a black finish; all capacities, dimensions, and power requirements are identical.
How is the MSC-6KLP-BLK loaded?
Drive-over ramps at 3-15/16 in height allow drive-over loading, and a pallet-jack feature also allows positioning the lift under the vehicle.
What's the maximum lift height?
72 in full rise height, requiring a minimum 9 ft ceiling clearance.
Is the MSC-6KLP-BLK portable?
Yes. As an iMOBILE lift, it can be moved and repositioned rather than permanently anchored to one location.
