Tuxedo 2,000 lb Single Column Multi-Use Storage/Service Lift #SC-2K-UTV-X
| Model / Part Number | SC-2K-UTV-X |
| Capacity | 2,000 lb |
| Type | Single column, high-rise, multi-use storage & service lift |
| Power | 115V, electric/hydraulic DURO power unit |
| Lock Positions | 20 |
| Ship Weight | 1,624 lb |
- Level, load-rated shop or garage floor
- Follow manufacturer anchoring specs in the installation manual
- Indoor use
- 115V electrical service for the included DURO electric/hydraulic power unit
- Power unit can be mounted to the front, side, or rear of the column for the best fit in your space
- Multi-adjustable platforms with multi-directional front & side loading accommodate a range of ATV/UTV/mower widths
- 8 multi-position side ramps and wheel-stop pivot ramps included
- Ships via LTL freight
iDEAL SC-2K-UTV-X — 2,000 lb Single Column Multi-Use Storage/Service Lift
The Tuxedo SC-2K-UTV-X is a 2,000 lb single-column, high-rise 'multi-use' storage and service lift built for most small to mid-sized ATVs, UTVs, golf carts, and riding/zero-turn mowers. Multi-adjustable platforms support multi-directional front and side vehicle loading, with spring-loaded quick-release locking nylon rollers and brackets mounted underneath each platform for fast width adjustment.
Each platform locks to the bolster with heavy-duty lock pins and retainer brackets once the desired width is set. The power unit can be mounted to the front, side, or rear of the column, letting you fit the lift into tight garage or shop layouts. It comes standard with a durable powder-coat finish, 8 multi-position side ramps, wheel-stop pivot ramps with protective nylon rollers, and quick-removal tubular wheel-stop bars.
Operation is via a 115V electric/hydraulic DURO power unit with an HD hydraulic chain-drive cylinder and single-point manual lock release across 20 different locking height positions — letting you store a vehicle overhead or lower it for service access.
Who It's Built For
- ✅ Homeowners, powersport dealers, and shops storing or servicing ATVs, UTVs, golf carts, and riding/zero-turn mowers
- ✅ Facilities wanting a space-saving single-column lift with flexible power-unit mounting
- ✅ Users who need both overhead storage and lowered service-height positions from one lift
What It's NOT Built For
- ❌ Vehicles or equipment over 2,000 lb
- ❌ Full-size automotive service — platform width and column design are sized for UTV/mower-class equipment
Questions about fit, freight, or capacity? Call Alamo at (817) 865-3707.
What Makes the SC-2K-UTV-X Different
Multi-Adjustable, Multi-Directional Platforms
Spring-loaded quick-release locking rollers let platforms adjust width quickly for front or side loading of different ATV, UTV, golf cart, and mower sizes.
Flexible Power Unit Mounting
The 115V DURO power unit can mount to the front, side, or rear of the column, helping the lift fit tight garage or shop layouts.
20 Locking Height Positions
A single-point manual lock release across 20 positions supports both high-rise overhead storage and lower service-height positions.
Included Ramps and Wheel Stops
Ships with 8 multi-position side ramps, wheel-stop pivot ramps with protective nylon rollers, and quick-removal tubular wheel-stop bars.
Footprint
Ship weight is 1,624 lb; confirm floor space and column mounting orientation before ordering.
✅ Best For
- ✅ Homeowners and shops needing overhead storage plus service access for one small to mid-sized ATV/UTV/mower
- ✅ Facilities with tight floor space that benefit from flexible power-unit mounting
- ✅ Users servicing multiple types of powersport/lawn equipment with adjustable platform widths
❌ Not Ideal For
- ❌ Equipment over 2,000 lb
- ❌ Automotive service bays — see Tuxedo's two-post or four-post lift lines for cars and trucks
SC-2K-UTV-X vs. MSC-6KLP — Which Single/Mobile Column Lift Fits Your Equipment?
Both are column-style lifts, but built for different vehicle classes and use cases.
| Decision Point | SC-2K-UTV-X | MSC-6KLP |
|---|---|---|
| Vehicle type | ATVs, UTVs, golf carts, riding/zero-turn mowers | Automobiles and light trucks |
| Capacity | 2,000 lb | 6,000 lb |
| Mobility | Fixed single-column storage lift | Mobile, portable single-column lift |
| Power | 115V electric/hydraulic DURO power unit | 115V, 15A single-phase |
Choose the SC-2K-UTV-X for storing and servicing ATVs, UTVs, and mowers; choose the MSC-6KLP for a mobile, portable lift rated for full-size automobiles. Call (817) 865-3707 with questions about fit.
Full Specifications — SC-2K-UTV-X
| Model / Part Number | SC-2K-UTV-X |
| Capacity | 2,000 lb |
| Type | Single column, high-rise, multi-use storage & service lift |
| Platform Design | Multi-adjustable, multi-directional front & side loading |
| Power | 115V electric/hydraulic DURO power unit |
| Lifting Mechanism | HD hydraulic chain-drive cylinder |
| Lock Release | Single-point manual, 20 locking height positions |
| Included | 8 multi-position side ramps, wheel-stop pivot ramps w/ nylon rollers, quick-removal tubular wheel-stop bars |
| Finish | Durable powder-coat |
| Ship Weight | 1,624 lb |
| Shipping Dimensions | 124 in L x 32 in W x 45 in H |
⚠️ Installation Requirements
- Floor: Level, load-rated shop or garage floor; follow manufacturer anchoring specs in the installation manual.
- Electrical: 115V service for the included DURO electric/hydraulic power unit.
- Placement: Decide front, side, or rear power-unit mounting based on your available floor space before installation.
- Freight: Standard freight delivery within the 48 contiguous United States is included in the advertised price.
- Installation: Call Alamo at (817) 865-3707 to coordinate delivery and setup guidance.
Warranty — SC-2K-UTV-X
For exact warranty terms and coverage on the SC-2K-UTV-X, please contact Alamo Equipment at (817) 865-3707.
❓ Frequently Asked Questions — SC-2K-UTV-X
Does the SC-2K-UTV-X price include shipping?
Yes. The advertised price includes standard freight delivery within the 48 contiguous United States. Additional freight charges apply for Alaska and Hawaii.
What can the SC-2K-UTV-X lift?
Most small to mid-sized ATVs, UTVs, golf carts, and riding/zero-turn mowers up to 2,000 lb.
Can the power unit be mounted in different positions?
Yes. The 115V DURO power unit can be mounted to the front, side, or rear of the column to fit your available space.
How many height positions does it have?
20 different locking height positions via a single-point manual lock release, supporting both storage and service heights.
What's included with the SC-2K-UTV-X?
8 multi-position side ramps, wheel-stop pivot ramps with protective nylon rollers, and quick-removal tubular wheel-stop bars.
